iOS (SwiftUI)

Capture the screens of a SwiftUI app and put them in your Scry project, where they are browsable build by build, and searchable by your AI assistant through the MCP server. This page walks through scry-sample-ios, a small SwiftUI app called Kettle, from clone to a build in your project, then shows how to do the same for your own app.

No code of yours is uploaded. Scry receives PNG screenshots and a small manifest, nothing else.

How capture works for native apps

Capture for SwiftUI and Compose is a reference script that lives in the sample app and in the Scry skill. It is not a built-in Scry command: you copy the script into your project, and the only Scry command involved is scry upload (run as npx @scrymore/scry-deployer upload). React Native is different: it has a built-in scry capture rn command, see React Native.

Before you start

• A Mac with Xcode 16 or later and an iOS Simulator runtime that includes the iPhone 16 device.
• Node.js 18 or later, which runs the Scry CLI through npx.
• A Scry project and a project API key (below).

Get a project API key

In the dashboard, open your project, then Settings ▸ General for the project ID and Settings ▸ API keys to generate a key. Keys are project-scoped: a key only uploads to the project it was created in. Copy the key when it is shown and keep it out of chat and committed files.

The API keys tab of your project settings.

1. Get the sample app

Clone the Kettle sample app, a small coffee-order app with three screens and two components. Build it with xcodebuild, then boot the iPhone 16 simulator, install the app and launch it with xcrun simctl. Kettle opens on its Menu screen, which is what Scry will capture.

git clone https://github.com/scryorg/scry-sample-ios.git
cd scry-sample-ios

xcodebuild -scheme Kettle -destination "platform=iOS Simulator,name=iPhone 16" -derivedDataPath .build build | tail -n 2
xcrun simctl bootstatus "iPhone 16" -b | tail -n 2
xcrun simctl install "iPhone 16" .build/Build/Products/Debug-iphonesimulator/Kettle.app
xcrun simctl launch "iPhone 16" com.scryorg.kettle

xcodebuild ends with ** BUILD SUCCEEDED **, bootstatus boots the simulator if it is not running and ends with Finished, and launch prints the app's bundle id and a process id. The screens are Menu, Item Detail and Order; the components are Button and QuantityStepper.

If you prefer Xcode, open Kettle.xcodeproj, choose the iPhone 16 simulator and press Run (⌘R). The video does not show this route.

Step 1 — cloning the sample, building it and launching it on the iPhone 16 simulator from the terminal.

2. Capture your screens

Run the capture script. It builds Kettle, boots the simulator, installs the app, then opens each registered screen by launch argument and takes a screenshot of it. When it finishes, .scry/capture holds one image per screen and a small manifest file.

./scripts/capture.sh

capture: simulator {{*}} ({{*}})
capture: building Kettle (Debug)...
capture: menu ok
capture: item-detail ok
capture: order ok
capture: button ok
capture: quantity-stepper ok
scf: 5/5 captured, 0 skipped -> .scry/capture
capture: bundle written to .scry/capture. Next: npx @scrymore/scry-deployer upload .scry/capture --dry-run

ls .scry/capture .scry/capture/images

In the expected output, a placeholder in double braces stands for a number or for any text. The script picks the simulator named iPhone 16; set DEVICE to use another. The launch argument is -ScryScreen <id>, and the bundle is a Scry Capture Format bundle. The five captures are Menu, Item Detail, Order, Button and QuantityStepper. If a screen never reports that it is ready, the script says so (capture: <id> never reported ready), lists it under counts.skipped in the manifest and exits 1, so a half-captured run never looks successful.

Add one of your own screens

Open Kettle/ScryScreens.swift and add one line to the registry: an id, a display name, the screen's source file and line, and the view with its fixed data. Run ./scripts/capture.sh again and the bundle holds six captures.

The id is the screen's identity across builds. Use a route or type name, never a title a person might edit.

Step 2 — the capture script opening each screen and writing the bundle.

3. Check the bundle

Check the bundle before you send anything. Run the upload command with the dry-run flag. It validates the bundle with the same validator the real upload uses, then stops. Nothing leaves your machine, and no key is needed.

npx @scrymore/scry-deployer upload .scry/capture --dry-run

Validating .scry/capture ...
✅ Bundle valid: 5 captures, source swiftui-preview:ios.
Dry run: not uploading. Bundle ZIP: {{*}}

The source line comes from the manifest: swiftui-preview:ios is how Scry knows this is SwiftUI on iOS. A rejected bundle prints every problem with its code (see Troubleshooting).

A valid bundle can still be a short one

The validator accepts a bundle that is missing screens, because the manifest lists them as skipped. Check the count in Bundle valid: N captures against the number of screens you registered, and look at the images in .scry/capture/images/ for a keyboard, a permission dialog, a loading spinner or a clipped status bar.

Step 3 — validating the bundle with --dry-run.

4. Upload

Now upload. Set your project id and API key as environment variables, then run the same command without the dry-run flag. It validates the bundle again, stores it, and prints the build number once the upload is queued for indexing.

export SCRY_PROJECT_ID=proj_xxxxxxxx
export SCRY_API_KEY=sk_live_xxxxxxxx

Replace both placeholders with the values from your project. The placeholders above are not real and are rejected if you use them.

npx @scrymore/scry-deployer upload .scry/capture

Validating .scry/capture ...
✅ Bundle valid: 5 captures, source swiftui-preview:ios.
Bundle stored ({{*}}, build #{{n}}).
Bundle complete: attempt 1/3, {{*}}, timeout {{n}} s...
Bundle complete: sent {{*}} in {{*}} s (attempt 1/3).
✅ Bundle uploaded (build #{{n}}).
⏳ Indexing has been queued, not finished. Components are searchable once the build shows processingStatus "completed".

The CLI reads SCRY_PROJECT_ID and SCRY_API_KEY itself. You can pass --project and --api-key instead, but then the key sits in your shell history, so prefer the environment.

Step 4 — uploading the bundle. The key shown is a placeholder.

5. See it in Scry

Open your project in the dashboard. The new build appears in the Builds tab with the source SwiftUI · iOS and a device line: your simulator's name, scale and screen count, for example iPhone 16 · 3× · 5 screens. Open the build to see them on its Capture tab.

The Builds tab: the source chip is SwiftUI · iOS.

A native build has no Storybook behind it, so there is no "Open in Storybook" link. The Builds tab, the source chips and the project's other capture sources are covered in Capture sources.

Step 5 — the new build, its device line and its Capture tab in the dashboard.

Use it

Once the build is indexed, its screens are searchable. This recording runs the same search the MCP server runs, for quantity stepper. A result from this build carries a Source line naming the Swift file and line in your code, plus its platform and source type; ranking depends on what else is in your project.

Step 6 — the same search the MCP server runs, for a screen by name.

A result from this build shows Source: <file>:<line>, the source file and line recorded in the capture, instead of a Storybook link. The search API response also carries the build's source_type and platform.

• Ask your assistant. Connect the MCP server and ask for a screen in plain words, for example quantity stepper. Each result names the screen and, when the capture recorded a source file, where it lives.
• See the builds in the dashboard. The Builds tab lists each build with its source, device and screen count; the Capture tab shows the device, scale and screens.
• Link screens to designs. Linking a native screen to a Figma frame from the Scry Link plugin is not available yet.

Put it in CI

The sample ships two GitHub Actions workflows in .github/workflows/:

• ci.yml builds and tests the app on every pull request, on a GitHub-hosted runner, with no secrets.
• scry-capture.yml captures and uploads, on a macOS runner, only on a push to the default branch. Pull requests from forks never reach it, so your key is never exposed to code you did not review.

Add the project id as a repository variable and the key as a repository secret:

Where	Name	Value
Repository variable	SCRY_PROJECT_ID	your project ID
Repository secret	SCRY_API_KEY	your project API key

The upload step in the workflow is the command from step 4:

      - name: Upload to Scry
        run: npx @scrymore/scry-deployer upload .scry/capture
        env:
          SCRY_PROJECT_ID: ${{ vars.SCRY_PROJECT_ID }}
          SCRY_API_KEY: ${{ secrets.SCRY_API_KEY }}

Make it your own

To turn the sample into a build in your own project, change four things:

1. The bundle id (the app's identifier) to your own, so the capture script launches your app.
2. The screens list in Kettle/ScryScreens.swift: replace the Kettle screens with yours, each with a stable id.
3. The project id: SCRY_PROJECT_ID.
4. The key: SCRY_API_KEY, from your project's Settings ▸ API keys.

Set up your own app with the Scry skill

Wiring an existing app for capture is the part of the native path that takes real work: your app needs a way to open one screen on its own, with fixed data and no sign-in, so the screenshot is the same every run. (React Native needs far less, because scry capture rn drives your Storybook directly.) The scry-native-capture-setup skill does that wiring with your AI coding assistant.

1. Install the skill in your app's repository:

npx skills add scryorg/scry-node --skill scry-native-capture-setup

The installer works with Claude Code, Codex and Cursor, and needs Node.js 22.20 or newer; see Set up with AI for the details.

2. Ask your assistant:

   Set up Scry capture for this app.

   The skill inspects your project and asks only what it cannot find: which screens matter, your project id, and whether you want CI. It adds:

   • a launch handler, ScryLaunch.swift (about 30 lines), that reads -ScryScreen <id> and shows only that screen. A normal launch is unchanged;
   • a registry file, ScryScreens.swift, mapping each screen id to its view;
   • fixtures, so each screen renders without sign-in or network;
   • scripts/capture.sh and scripts/make-scf.mjs;
   • optionally, the CI workflow.

3. It checks its own work when it can. If a simulator is available where the assistant runs, it runs capture.sh and upload --dry-run and shows you the screenshots; otherwise it lists the commands for you to run on a Mac. It never uploads, and never touches your API key, without your go.

4. Tools needed on the machine or runner: Xcode with an iOS Simulator runtime, Node.js, and the Scry CLI (npx @scrymore/scry-deployer).

The skill setting up a bare app for capture. The same video appears on the iOS, Android and [Set up with AI](/guide/skill) pages.

The skill adds no dependency to your app and does not change a release build: the capture paths run only when the app is launched with the capture argument. It does not cover UIKit-only apps. For a Flutter app, see Flutter.

What the skill adds, if you would rather do it by hand

The sample app is the worked example of each piece. Copy them from scry-sample-ios:

Piece	File	What it does
Launch hook	ScryLaunch.swift	reads -ScryScreen <id>; renders only that screen on a fixed canvas, with no animation
Screen registry	ScryScreens.swift	one entry per screen: id, name, source file and line, the view
Fixtures	Fixtures.*	fixed data written from your app's own model types, so a screen never waits on the network or the clock
Capture script	scripts/capture.sh	opens each screen, waits until it reports ready, takes the screenshot, then calls the bundle writer
Bundle writer	scripts/make-scf.mjs	writes scf.json and images/<id>.png
CI	.github/workflows/scry-capture.yml	captures and uploads on a push to the default branch

Wire the launch hook into your app's entry point so that a normal launch shows your usual first screen and only the capture argument selects a single screen.

For another tool, or for a script of your own, the bundle format is documented on Capture bundle format.

Troubleshooting

HTTP 401 Unauthorized - Authentication required The upload reached Scry without an API key. The service's own message is Missing X-API-Key header. Check that SCRY_API_KEY is set in the shell that runs the upload (test -n "$SCRY_API_KEY" && echo set || echo missing), then run it again. In CI, check that the repository secret exists and that the workflow passes it in env. If the response carries a request id, the CLI prints a Ref: line; quote it when you contact us.

HTTP 401 Unauthorized - Invalid API key format The value is not a Scry project key. The placeholder sk_live_xxxxxxxx on this page produces exactly this error; copy a real key from Settings ▸ API keys.

HTTP 403 Forbidden - Project mismatch The key belongs to a different project than the one you uploaded to. A key only works for the project it was created in: use the key from the same project as SCRY_PROJECT_ID.

❌ --project is required to upload. SCRY_PROJECT_ID is not set and no --project was passed. --dry-run works without it; a real upload does not.

❌ The bundle was rejected by the Scry Capture Format validator. Nothing was uploaded. The lines below it name the problem and its code. Four you may meet:

  error DUPLICATE_ID [menu]: Duplicate capture id (2×): menu
  error IMAGE_HEADER_UNREADABLE [menu]: Could not read image dimensions from the header: images/menu.png
  error STRUCTURE_PATH_INVALID [Screens/Home--Default]: structure.file must be a .json path under structure/: structure/evil.html
  error FORBIDDEN_MEMBER [structure/evil.html]: Bundle member is not referenced by any capture: structure/evil.html

DUPLICATE_ID means two entries in your screens list share an id: each screen needs its own. IMAGE_HEADER_UNREADABLE means a screenshot file is empty or cut short, which usually follows a capture that was interrupted: run ./scripts/capture.sh again. STRUCTURE_PATH_INVALID means a capture's structure.file points at something that is not a .json file under structure/ (an .html file, for example): point it at the structure tree your adapter wrote, or drop the structure entry. FORBIDDEN_MEMBER means the bundle holds a file that no capture refers to (here the stray structure/evil.html): delete the extra file from the bundle folder and run the capture again, so the folder holds only scf.json, the images and the files the manifest names.

scf: 4/5 captured, 1 skipped and exit code 1. A screen never reported ready, so its image is missing. The capture script names it: capture: <id> never reported ready. Open that screen by hand with the launch argument, fix what blocks it (usually data that waits on the network, a sign-in, or a permission prompt), and capture again. upload --dry-run still says the bundle is valid with four captures, because the skipped screen is listed in the manifest, so do not treat a short count as success.

The build is in the Builds tab but has no screens yet. Indexing runs after the upload: the CLI prints Indexing has been queued, not finished and the screens become searchable once the build is processed. Refresh the Builds tab in a minute.

A simulator or emulator problem. If the script prints capture: no simulator named "iPhone 16" found., install an iOS runtime in Xcode (Settings, Components), then run xcrun simctl list devices available | grep -i iphone, pick a name and run DEVICE="<name>" ./scripts/capture.sh. If it prints capture produced 0 screens, no screen reported ready: look at the lines above it. If you cannot get a device running, the skill stops and prints the exact commands for you to run instead of claiming a capture.

For problems with the Scry CLI itself, see Troubleshooting.

Privacy and data

An upload sends the bundle and nothing else from your project: the PNG screenshots, and scf.json, which lists each screen's id, name, title, its device and scale, and the source file and line you registered for it (a path and a number, not the code). The upload also carries the commit SHA and branch name it is run from (read from your CI environment or the local git checkout). No source text is uploaded: --include-source, the option that would also upload each capture's source file, is off by default and this page never uses it.

The capture script runs entirely on your machine, and the Scry skill never uploads without your go. The CLI reports errors to Scry's error tracker (errors only); set SCRY_TELEMETRY=0 or DO_NOT_TRACK=1 to turn that off.

Feedback and support

Something broke or felt wrong? Tell us on the feedback form or email feedback@scrymore.com. Include the Ref: line from the CLI if it printed one.

Changelog

• First version of this page.
